Randomization with Flexible Block Sizes with randomforge

Friedrich Pahlke

2025-11-26

Source: vignettes/randomforge_flexible_pbr_example.Rmd
randomforge_flexible_pbr_example.Rmd

Introduction

This vignette provides a practical example for randomforge. It demonstrates:

  • How to define treatment arms
  • How to configure project-level randomization
  • How do you implement permuted block randomization (PBR) with a fixed starting block size and continuation with variable block sizes
  • How to perform quality control of random values
  • How to extract and inspect the generated randomization list

Loading the randomforge Package

library(randomforge)
#> randomforge developer version 0.1.0.9046 loaded

Trial Setup

Treatment Arms

treatmentArmIds = c("Treatment", "Control")

Maximum Number of Subjects per Center

maxNumberOfSubjects <- 40

Seed

The seeds in this example will be generated via
random.org

seed <- createSeed()
seed
#> [1] 1379678

Creating Project and Configuration

randomDataBase <- getRandomDataBase()

randomProject <- getRandomProject(name = "Flexible PBR Example Trial")
randomDataBase$persist(randomProject)

randomConfiguration <- getRandomConfiguration(
    randomProject = randomProject,
    treatmentArmIds = treatmentArmIds,
    seed = seed
)
randomDataBase$persist(randomConfiguration)

ravService <- getRandomAllocationValueService()

Initial Randomization Using Fixed Block Size

Define Initial Block Length

initialBlockLength <- 8
randomMethod <- getRandomMethodPBR(
    blockSizes = getBlockSizes(treatmentArmIds, initialBlockLength)
)
for (i in 1:initialBlockLength) {
    suppressMessages(getNextRandomResult(
        randomDataBase, randomProject, randomMethod, ravService
    ))
}

Variable Block Sizes for Remaining Subjects

Define Candidate Block Sizes

blockSizes <- getBlockSizes(treatmentArmIds, c(4, 6))
blockSizeRandomizer <- getRandomBlockSizeRandomizer(
    blockSizes = blockSizes,
    seed = 2758500)
blockSizeRandomizer$initRandomValues(numberOfBlockSizes = length(blockSizes))

Randomize Remaining Subjects

randomMethod <- getRandomMethodPBR(
    blockSizes = blockSizes,
    fixedBlockDesignEnabled = FALSE,
    blockSizeRandomizer = blockSizeRandomizer
)

for (i in 1:(maxNumberOfSubjects - initialBlockLength)) {
    suppressMessages(getNextRandomResult(
        randomDataBase, randomProject, randomMethod, ravService
    ))
}

Quality Control

Distribution of Used Random Values

plot(ravService)

No significant deviation from a uniform distribution is detected (p > 0.05).

Distribution of All Generated Random Values

plot(ravService, usedValuesOnly = FALSE)

Output: Randomization List

randomList <- as.data.frame(randomDataBase)
knitr::kable(randomList)
project random-number treatment-arm status overall-levels-Treatment overall-levels-Control block-wise-levels-Treatment block-wise-levels-Control randomization-decision unique-subject-id
Flexible PBR Example Trial 1 Treatment RANDOMIZED 1 0 Treatment:1/4 Control:0/4 range-set[Treatment=[0,0.5], Control=[0.5,1]; rav=0.0212203289847821] d8c8ac28-71fa-4057-92d5-de6367c1322d
Flexible PBR Example Trial 2 Treatment RANDOMIZED 2 0 Treatment:2/4 Control:0/4 range-set[Treatment=[0,0.5], Control=[0.5,1]; rav=0.1417948291637] 705e5507-18ea-473e-afba-2390c44b3f18
Flexible PBR Example Trial 3 Control RANDOMIZED 2 1 Treatment:2/4 Control:1/4 range-set[Treatment=[0,0.5], Control=[0.5,1]; rav=0.703004920156673] 3710dc82-6f09-413e-b7ca-5496b16fda9f
Flexible PBR Example Trial 4 Control RANDOMIZED 2 2 Treatment:2/4 Control:2/4 range-set[Treatment=[0,0.5], Control=[0.5,1]; rav=0.525561064947397] 4c869b36-a77c-4323-9d39-360ddd60669c
Flexible PBR Example Trial 5 Treatment RANDOMIZED 3 2 Treatment:3/4 Control:2/4 range-set[Treatment=[0,0.5], Control=[0.5,1]; rav=0.145504052750766] 8667d6a0-8108-4613-8d9b-ad7b0ba28626
Flexible PBR Example Trial 6 Treatment RANDOMIZED 4 2 Treatment:4/4 Control:2/4 range-set[Treatment=[0,0.5], Control=[0.5,1]; rav=0.408401624765247] 8c92c5af-91f8-4e53-9cab-538910e009b7
Flexible PBR Example Trial 7 Control RANDOMIZED 4 3 Treatment:4/4 Control:3/4 range-set[Treatment=[0,0], Control=[0,1]; rav=0.526814301963896] df2e3225-2afa-4775-b579-976ce26a2e7d
Flexible PBR Example Trial 8 Control RANDOMIZED 4 4 Treatment:4/4 Control:4/4 range-set[Treatment=[0,0], Control=[0,1]; rav=0.828539446461946] 9713461a-aa6d-456f-9795-b15771c93969
Flexible PBR Example Trial 9 Control RANDOMIZED 4 5 Treatment:0/2 Control:1/2 range-set[Treatment=[0,0.5], Control=[0.5,1]; rav=0.615094124572352] 97d824d7-a6ea-44af-8926-e16757ec9cce
Flexible PBR Example Trial 10 Treatment RANDOMIZED 5 5 Treatment:1/2 Control:1/2 range-set[Treatment=[0,0.5], Control=[0.5,1]; rav=0.194894318003207] dbf2d7a5-a55a-4d2a-83ea-76dc6eb4289a
Flexible PBR Example Trial 11 Treatment RANDOMIZED 6 5 Treatment:2/2 Control:1/2 range-set[Treatment=[0,0.5], Control=[0.5,1]; rav=0.014120080973953] b4add5e6-a2b2-458c-a2fc-aea5644f0321
Flexible PBR Example Trial 12 Control RANDOMIZED 6 6 Treatment:2/2 Control:2/2 range-set[Treatment=[0,0], Control=[0,1]; rav=0.180169035680592] 2f0dccc1-be46-4cb9-b0f1-2bccb95ced45
Flexible PBR Example Trial 13 Treatment RANDOMIZED 7 6 Treatment:1/3 Control:0/3 range-set[Treatment=[0,0.5], Control=[0.5,1]; rav=0.246198229491711] d65143fb-d9da-4cdb-90bf-d96eaf0741a9
Flexible PBR Example Trial 14 Control RANDOMIZED 7 7 Treatment:1/3 Control:1/3 range-set[Treatment=[0,0.5], Control=[0.5,1]; rav=0.508522406220436] f09c59af-b573-4a58-b6ae-f0c37065af1b
Flexible PBR Example Trial 15 Treatment RANDOMIZED 8 7 Treatment:2/3 Control:1/3 range-set[Treatment=[0,0.5], Control=[0.5,1]; rav=0.000603425083681941] 440feba7-f93c-4ee9-9c43-9ead56dfe41c
Flexible PBR Example Trial 16 Control RANDOMIZED 8 8 Treatment:2/3 Control:2/3 range-set[Treatment=[0,0.5], Control=[0.5,1]; rav=0.867856977041811] 8f5f460e-3c10-4670-9d02-a9848c5c223a
Flexible PBR Example Trial 17 Control RANDOMIZED 8 9 Treatment:2/3 Control:3/3 range-set[Treatment=[0,0.5], Control=[0.5,1]; rav=0.871452651685104] 8b3cc7ae-fb21-45a9-8640-0689d485fe7d
Flexible PBR Example Trial 18 Treatment RANDOMIZED 9 9 Treatment:3/3 Control:3/3 range-set[Treatment=[0,1], Control=[1,1]; rav=0.758590350393206] c94876be-fa26-4a84-b239-ac9d892d907c
Flexible PBR Example Trial 19 Treatment RANDOMIZED 10 9 Treatment:1/2 Control:0/2 range-set[Treatment=[0,0.5], Control=[0.5,1]; rav=0.179464610526338] 12d50f53-ffa8-42e6-a723-d23c7d44b0ff
Flexible PBR Example Trial 20 Control RANDOMIZED 10 10 Treatment:1/2 Control:1/2 range-set[Treatment=[0,0.5], Control=[0.5,1]; rav=0.943183079361916] d86c27d0-de1f-4d06-b848-1d9e5ee02cdd
Flexible PBR Example Trial 21 Control RANDOMIZED 10 11 Treatment:1/2 Control:2/2 range-set[Treatment=[0,0.5], Control=[0.5,1]; rav=0.763430547900498] 58fefd66-59e0-48ca-86c7-acf3d4e4fd18
Flexible PBR Example Trial 22 Treatment RANDOMIZED 11 11 Treatment:2/2 Control:2/2 range-set[Treatment=[0,1], Control=[1,1]; rav=0.773297929903492] 3500d8f7-2301-4d57-854b-f9b2c67e58a1
Flexible PBR Example Trial 23 Control RANDOMIZED 11 12 Treatment:0/2 Control:1/2 range-set[Treatment=[0,0.5], Control=[0.5,1]; rav=0.591403880855069] 83596c0b-c80d-4de4-939a-367d37edbe57
Flexible PBR Example Trial 24 Control RANDOMIZED 11 13 Treatment:0/2 Control:2/2 range-set[Treatment=[0,0.5], Control=[0.5,1]; rav=0.785737928934395] cf554ae9-4510-4730-8920-48869788b52b
Flexible PBR Example Trial 25 Treatment RANDOMIZED 12 13 Treatment:1/2 Control:2/2 range-set[Treatment=[0,1], Control=[1,1]; rav=0.296541688032448] 75c79aea-bd56-4353-81f3-8c89a4203690
Flexible PBR Example Trial 26 Treatment RANDOMIZED 13 13 Treatment:2/2 Control:2/2 range-set[Treatment=[0,1], Control=[1,1]; rav=0.0567047209478915] 6ee0eed0-13a8-42ba-b2d8-38b87c3135cf
Flexible PBR Example Trial 27 Control RANDOMIZED 13 14 Treatment:0/3 Control:1/3 range-set[Treatment=[0,0.5], Control=[0.5,1]; rav=0.73090074188076] 2754df2a-d8d4-4822-920e-c27366b99304
Flexible PBR Example Trial 28 Treatment RANDOMIZED 14 14 Treatment:1/3 Control:1/3 range-set[Treatment=[0,0.5], Control=[0.5,1]; rav=0.110916475299746] b896c3d8-e082-4c0f-861d-14928a2b6ecf
Flexible PBR Example Trial 29 Control RANDOMIZED 14 15 Treatment:1/3 Control:2/3 range-set[Treatment=[0,0.5], Control=[0.5,1]; rav=0.887901743175462] d7b35bbc-3bbe-4e5a-882c-3105bca9710f
Flexible PBR Example Trial 30 Treatment RANDOMIZED 15 15 Treatment:2/3 Control:2/3 range-set[Treatment=[0,0.5], Control=[0.5,1]; rav=0.125286859693006] 2e0e625c-2b86-41ab-b46e-9cd7a2b1b24e
Flexible PBR Example Trial 31 Control RANDOMIZED 15 16 Treatment:2/3 Control:3/3 range-set[Treatment=[0,0.5], Control=[0.5,1]; rav=0.727101013064384] 011d192e-a8a2-4b10-8f18-ecc328e8b5ee
Flexible PBR Example Trial 32 Treatment RANDOMIZED 16 16 Treatment:3/3 Control:3/3 range-set[Treatment=[0,1], Control=[1,1]; rav=0.0377451616805047] c37c48a9-a9c4-4cc9-9654-1408b2f9ecd2
Flexible PBR Example Trial 33 Control RANDOMIZED 16 17 Treatment:0/2 Control:1/2 range-set[Treatment=[0,0.5], Control=[0.5,1]; rav=0.52538527501747] 6f9642d7-3f76-49dd-aa51-8daa2643c2a7
Flexible PBR Example Trial 34 Treatment RANDOMIZED 17 17 Treatment:1/2 Control:1/2 range-set[Treatment=[0,0.5], Control=[0.5,1]; rav=0.0736770003568381] 8a5802f7-b923-40c5-8434-4b7f8e73fe83
Flexible PBR Example Trial 35 Treatment RANDOMIZED 18 17 Treatment:2/2 Control:1/2 range-set[Treatment=[0,0.5], Control=[0.5,1]; rav=0.485733987297863] 6b8d5917-ec03-4749-9b0c-c43729f8caba
Flexible PBR Example Trial 36 Control RANDOMIZED 18 18 Treatment:2/2 Control:2/2 range-set[Treatment=[0,0], Control=[0,1]; rav=0.719684938434511] a2ea2481-ee6e-4b6c-a8af-1703270ab886
Flexible PBR Example Trial 37 Control RANDOMIZED 18 19 Treatment:0/2 Control:1/2 range-set[Treatment=[0,0.5], Control=[0.5,1]; rav=0.965410947334021] 8f79dc09-8d63-49bd-bd3d-5da611b40a1b
Flexible PBR Example Trial 38 Control RANDOMIZED 18 20 Treatment:0/2 Control:2/2 range-set[Treatment=[0,0.5], Control=[0.5,1]; rav=0.812460775719956] 2c8c34c8-b2d7-467c-adf8-5b9d32eaf311
Flexible PBR Example Trial 39 Treatment RANDOMIZED 19 20 Treatment:1/2 Control:2/2 range-set[Treatment=[0,1], Control=[1,1]; rav=0.205702553037554] 8d116bc5-5097-485c-8da3-f7da3a2542c1
Flexible PBR Example Trial 40 Treatment RANDOMIZED 20 20 Treatment:2/2 Control:2/2 range-set[Treatment=[0,1], Control=[1,1]; rav=0.0162965569179505] 5d876423-2257-4154-ac1a-ba104cf1b485

System Information

  • System: R version 4.5.2 (2025-10-31)
  • randomforge version: 0.1.0.9046
  • Platform: x86_64-pc-linux-gnu
  • Working directory: /home/runner/work/randomforge/randomforge/vignettes
